SMC Networks ISE80 - Units Selection [F0]

-23-
No.PS※※-OMM0003-J
■[F 0] Units selection function
Only the product with Units selection function can be set.
The displayed unit can be changed, and depends on the pressure range.
(Refer to the table below for the minimum indication unit).
(kPa/MPa units are available when the product does not have the units selection function.)
<Operation>
Press the
or button in function selection mode to display [F 0].
Press the
button.
Move on to select the display unit.
Press the
button to set.
Return to function selection mode.
Setting of [F 0] Units selection function completed
•Display unit and minimum setting unit
Unit
ZSE80F
ZSE80
ISE80
ISE80H
MPa 0.001 0.001 0.001
0.001 (to 1.999)
0.01 (2.00 to)
kPa
0.1
0.1
1
-
kgf/cm
2
0.001 0.001 0.01
0.01 (to 19.99)
0.1 (20.0 to)
bar 0.001 0.001 0.01
0.01 (to 19.99)
0.1 (20.0 to)
psi 0.01 0.01 0.1
0.1 (to 199.9)
1 (200 to)
InHg 0.1 0.1 - -
mmHg
1
1
-
-
Select the Display Unit
Press the or button to select the display unit.
