SMC Networks ISE80 User Manual

-50-
No.PS※※-OMM0003-J
Specification
■Specifications
Model No.
ISE80
(positive pressure)
ISE80H
(positive pressure)
ZSE80
(vacuum)
ZSE80F
(compound)
Rated pressure range -0.1 to 1 MPa -0.1 to 2 MPa 0 to –101 kPa -100 to 100 kPa
Set pressure range
-0.105 to 1.1 MPa
-0.105 to 2.2 MPa
10 to –111 kPa
-110 to 110 kPa
Withstand pressure
2 MPa
4 MPa
500 kPa
Setting and display resolution 0.001 MPa
0.001 MPa
(1.999 MPa)
0.01 MPa
(2.00 to 2.20 MPa)
0.1 kPa
Port material
Pressure sensor: SUS630, Fitting: SUS304
Fluid
Fluid which has no corrosive effect on SUS630, SUS304
Connection port
R1/4, NPT1/4, G1/4, URJ1/4, TSJ1/4, Rc1/8
Piping direction: Rear or Bottom
Power supply voltage
12 to 24 VDC
±
10% with voltage ripple or less
Current consumption
45 mA or less
Protection
Protected against reverse connection
Switch output NPN1 output, NPN2 output, PNP1 output, PNP2 output
Max. load current
80 mA
Max. applied voltage
28 V (NPN output)
Residual voltage
1 V or less (80 mA load current)
Response time
2.5 ms (with anti-chatter function: 20, 100, 500, 1000, 2000 ms selectable)
Short circuit protection
Provided
Repeatability
±
0.2% F.S.
±
1 digit
Hysteresis
Hysteresis mode
0 to variable
∗1
Window comparator mode
Analogue
output
Voltage
output
∗2
Output voltage
0.6 to 5 V
±2.5% F.S.
Linearity: ±1% F.S.
0.8 to 5V
±2.5% F.S.
Linearity: ±1% F.S.
1 to 5V
±2.5% F.S.
Linearity: ±1% F.S.
Output impedance
Approx. 1 k
Ω
Current
output
∗3
Output current
2.4 to 20 mA
±2.5% F.S.
Linearity: ±1% F.S.
3.2 to 20 mA
±2.5% F.S.
Linearity: ±1% F.S.
4 to 20 mA
±2.5%F.S.
Linearity: ±1% F.S.
Load impedance
Max. load impedance: 300 Ω (power supply voltage of 12 V)
: 600 Ω (power supply voltage of 24 V)
Min. load impedance: 50
Ω
Auto shift input
Non-voltage input (reed or solid state), Low level 0.4 V or less,
input times 5 ms or more
Display
3 1/2 digits, 7-segment display, dual-colour display (red/green)
Display accuracy
±
2% F.S.
±
1 digit (ambient temperature 25
±
3
o
C)
Indicator LED
OUT1/OUT2: ON when LED is ON (Orange)
Functions
Anti-chatter function, Zero clear, Key lock, Auto pre-set,
Display unit selection, Power saving mode, Auto shift
∗1: If the applied voltage fluctuates around the set value, the hysteresis must be set to more than the fluctuation width. Otherwise,
chattering will occur.
∗2: If analogue voltage output is selected, the analogue current output cannot be selected.
∗3: If analogue current output is selected, the analogue voltage output cannot be selected.
