-51-
No.PS※※-OMM0003-J
Model No.
ISE80
(positive pressure)
ISE80H
(positive pressure)
ZSE80
(vacuum)
ZSE80F
(compound)
Environment
Enclosure
IP65
Ambient temperature
Operation: 0 to 50
o
C, Storage: -10 to 60
o
C (No condensation or freezing)
Ambient humidity
Operation, Storage: 35 to 85% RH (No condensation)
Withstand voltage
250 VAC for 1 minute Between wires and case
Insulation resistance
2 M
Ω
or more (50 VDC by megameter) Between wires and case
Temperature characteristic
±
3% F.S. (25
°
C Ambient temperature range))
Lead wire
Oil resistant vinyl cabtyre cable
3 cores (N.P) φ3.5, 2 m
4 cores (A.B) Sectional area of conductor: 0.15 mm
2
(AWG26)
5 cores (R.T.S.V) Outside diameter of insulator: 0.95 mm
Standard
CE marked (EMC directive/RoHS directive), UL/CSA
○Piping specifications
Model No.
02
N02
F02
C01
A2
B2
Port size
R1/4
NPT1/4
G1/4
Rc1/8
URJ1/4
TSJ1/4
Mass (Bottom ported)
117 g
118 g
-
114 g
120 g
111 g
Mass (Rear ported)
89 g
90 g
86 g
86 g
92 g
83 g
Leakage
1x10
-5
Pa●m
3
/s
1x10
-10
Pa●m
3
/s
○Analogue output
Voltage output
Current output
Range
Rated pressure range
A
B
C
Vacuum
0.0 to -101.0 kPa
-
0
-101.0 kPa
Compound
-100.0 to 100.0 kPa
-
-100 kPa
100 kPa
Positive pressure
-0.100 to 1.000 MPa
-0.1 MPa
0
1 MPa
-0.100 to 2.00 MPa
-0.1 MPa
∗
0
2 Mpa
∗: Analogue output is 0.8 [V] or 3.2 [mA] at the pressure A.
