Communication specification (During IO-Link mode)
IO-Link type
Device
IO-Link version
V1.1
Communication speed
COM2 (38.4 kbps)
Configuration file
IODD file
1
Min. cycle time
5.8 ms
Process data length
Input Data: 12 byte, Output Data: 0 byte
On request data communication
Available
Data storage function
Available
Event function
Available
Vendor ID
131 (0x0083)
Device ID
2
PF3A801H-L2-: 562 (0x0232)
PF3A802H-L2-: 563 (0x0233)
1: The configuration file can bedownloaded from the SMC website. (URL https://www.smcworld.com)
2: The Device ID varies depending on the output specification of the product.
Cable specification for M12 connector and lead wire (ZS-37-A, ZS-49-A)
Item
Specifications
Conductor
Nominal cross section
AWG23
Insulator
O.D.
Approx. 1.1 mm
Colours
Brown, blue, black, white
Sheath
Finish O.D.
ø4
