SMC Networks PF3A801H-L User Manual

-32-
No.PF※※-OMY0005
■Default setting
Function
Default Settings
Sub display
(Right)
Applicable
Page
Main display
(Right)
Main display
(Left)
Sub display
(Left)
[F 0]
FLoW
[rEF ] Select display units
[ Std] Standard condition
Page 33
FLoW
[Unit] Units selection function
1
[ L] L/min
tEMP
[ C]
o
C
PrES
[ MPA] MPa
-
[NorP] Select NPN/PNP
[ PNP] PNP output
[oUt1] Select the output of OUT1
[FLoW] Flow rate
[oUt2] Select the output of OUT2
[FLoW] Flow rate
[CoL ] Select display colour
[1SoG] Green when ON
Red when OFF (OUT1)
[F 1]
oUt1
[SW1 ] Select the target for setting
[FLoW] Flow rate
Page 37
FLoW
[ModE] Select switch mode
[ HYS] Hysteresis mode
FLoW
[1ot ] Select switch operation
[ 1_P] Normal output
FLoW
[P_1 ] Input the set value
[ 500] 500 L/min (PF3A801H)
[1000] 1000 L/min (PF3A802H)
FLoW
[H_1 ] Input of hysteresis
[ 50] 50 L/min (PF3A801H)
[ 100] 100 L/min (PF3A802H)
FLoW
[dtH1] ON delay time setting
[0.00] 0 s
FLoW
[dtL1] OFF delay time setting
[0.00] 0 s
[F 2]
oUt2
[SW2 ] Select the target for setting
[FLoW] Flow rate
Page 44
FLoW
[ModE] Select switch mode
[ HYS] Hysteresis mode
FLoW
[2ot ] Select switch operation
[ 2_P] Normal output
FLoW
[P_2 ] Input the set value
[ 500] 500 L/min (PF3A801H)
[1000] 1000 L/min (PF3A802H)
FLoW
[H_2 ] Input of hysteresis
[ 50] 50 L/min (PF3A801H)
[ 100] 100 L/min (PF3A802H)
FLoW
[dtH2] ON delay time setting
[0.00] 0 second
FLoW
[dtL2] OFF delay time setting
[0.00] 0 second
[F 3]
FLoW
[FiL ] Select digital filter
[ 1.0] 1 second
Page 45
PrES
[0.10] 0.1 second
[F 6]
PrES
[FSC ] Display value fine adjustment
[ 0.0] 0%
Page 46
[F13]
-
[rEv ] Select reverse display
[ oFF] Reverse display OFF
Page 47
[F14]
FLoW
[CUt ] Select Zero cut-off setting
[ 1.0] 1%F.S. cut
Page 48
PrES
[ 0.0] 0%
[F16]
PrES
[MES ] Measurement display setting
[diSP] Display
Page 52
tEMP
[diSP] Display
AC
[diSP] Display
[F30]
AC
[SAvE] Accumulated value hold
[ oFF] Not stored
Page 53
[F80]
-
[diSP] Display OFF mode
[ on] Display ON
Page 54
[F81]
[Pin ]Security code
[ oFF] Not used
Page 55
[F90]
[ALL ] Setting of all functions
[ oFF] Not used
Page57
[F96]
[CYCL] Check of cycle time
[ - - -. - ] No input signal
Page 59
[F98]
[tESt] Setting of output check
[ n] Normal output
Page 60
[F99]
[ini ] Reset to the default settings
[ oFF] Not used
Page 68
1: Setting is only possible for models with the units selection function.
