SMC Networks PF3A801H-L User Manual

-96-
No.PF※※-OMY0005
Specifications
Models
PF3A801H
PF3A802H
Fluid
Applicable fluid
1
Air, N
2
Operating fluid temperature
0 to 50
o
C
Flow specifications
Detection method
Heating type sensor (branch flow type)
Rated flow range
10 to 1000 L/min
20 to 2000 L/min
Set flow rate
range
2
Instantaneous
flow
10 to 1050 L/min
20 to 2100 L/min
Accumulated
flow
0 to 9,999,999,990 L
Lowest
configurable
increment
Instantaneous
flow
1 L/min
2 L/min
Accumulated
flow
10 L
Accumulated volume per pulse
(Pulse width = 50 msec.)
Select from 10 L/pulse, 100 L/pulse
Accumulated value hold
3
2 or 5 minutes can be selected..
Pressure
specifications
Rated pressure range
0.000 to 1.000 MPa
Set pressure range
2
-0.050 to 1.050 MPa
Lowest configurable increment
0.001 MPa
Proof pressure
1.5 MPa
Pressure loss
Refer to the pressure loss graph
Temp.
specifications
Rated temperature range
0.0 to 50.0
o
C
Set temperature range
-10.0 to 60.0
o
C
Lowest configurable increment
0.1
o
C
Electrical
specifications
Power supply voltage
21.6 to 30 VDC
Current consumption
150 mA or less
Protection
Polarity protection
Accuracy
Accuracy
Flow rate
4
±3.0%F.S.
Pressure
±3.0%F.S.
Temp.
5
±2.5
o
C.
Repeatability
(Flow rate/Pressure)
±1.0%F.S.
Temperature characteristics
(Flow rate/Pressure)
±5.0%F.S.( Ambient temp. 0 to 50
o
C, 25
o
C standard)
Pressure characteristics
(Flow rate)
6
±5.0%F.S. (0 to 1.0 MPa, 0.5 MPa standard)
Impact when modular devices
are connected (Flow rate)
7
±5.0%F.S.
