SMC Networks PF3A801H-L User Manual

-97-
No.PF※※-OMY0005
Models
PF3A801H
PF3A802H
Switch output
Output type
Select from PNP open collector or NPN open collector (2 outputs)
Output mode
Hysteresis mode, window comparator mode, error output, output OFF,
accumulated output and accumulated pulse output (Only flow rate)
Switch operation
Select from normal output or reversed output
Maximum load current
80 mA
Maximum applied voltage
(Only NPN)
30 VDC
Internal voltage drop
(Residual voltage)
1.5 V or less ((at load current 80 mA)
Response time
5 ms or less
Delay time
8
Variable at 0 to 60 s/0.01 s step
Hysteresis
9
Variable from 0
Protection
Over current protection
Display
Reference condition
10
Select from Standard condition or Normal condition
Unit
11
Instantaneous
flow
L/min, CFM (ft
3
/min)
Accumulated
flow
L, ft
3
Pressure
MPa. KPa, kgf/cm
2
, bar, psi
Temp.
o
C,
o
F
Display range
Instantaneous
flow
12
0 to 1050 L/min
(Displays 0 when the value
is below 10 L/min.)
0 to 2100 L/min
(Displays 0 when the value
is below 20 L/min.)
Accumulated
flow
0 to 9,999.99 x 10
6
L (6 digit display)
0 to 9,999,999.99 x 10
3
L (9 digit display)
Pressure
12
-0.050 to 1.050 MPa
Temp.
-10.0 to 60.0
o
C
Min. display
unit
Instantaneous
flow
1 L/min
2 L/min
Accumulated
flow
10 L
Pressure
0.001 MPa
Temp.
0.1
o
C
Display
Display method: LCD
Number of displays: 4
Display colour (upper line:): Red and green
Display colour (lower line:): Orange
Display (upper line/lower line): 10 digits
(7 segment 5digits, 11 segment 5 digits)
Operation LED
OUT LED: Orange is ON when output is ON
