-78-
No.PF※※-OMY0005
■IO-Link parameter setting
○IODD file
IODD (I/O Device Description) is a definition file which provides all properties and parameters required for
establishing functions and communication of the device.
IODD includes the main IODD file and a set of image files such as vendor logo, device picture and device
icon.
The IODD file is shown below.
Product No.
IODD file

PF3A8H-L2*-
SMC-PF3A8H-L2--yyyymmdd-IODD1.1
: "" indicates the product No., and the product No. applicable to each IODD file input.
: "yyyymmdd" indicates the file preparation date. yyyy is the year, mm is the month and dd is the date.
The IODD file can be downloaded from the SMC Web site (https://www.smcworld.com).
○Service data
The tables below indicates the parameters which can be read or written by simple access parameter (direct
parameters page) and ISDU parameters which are applicable to various parameters and commands.
●Direct parameters page 1
DPP1 address
Access
Parameter name
Initial value (dec)
Content
0x07
R
Vendor ID
0x0083(131)
"SMC Corporation"
0x08
0x09
R
Device ID
0X0232(562)
0X0233(563)
PF3A801H-L2x-xxx
PF3A802H-L2x-xxx
0x0A
0x0B
