-47-
No.PF※※-OMY0005
■[F13] Setting for reverse display mode
This function is used to rotate display upside down.
It is used to correct the display when it is upside down due to installation of the product.
When the reverse display function is ON, the function of the UP/DOWN buttons are reversed.
<Operation>
Display [F13] by pressing UP or DOWN button in function selection mode.
Press the SET button. Move on to select reverse display.
Select reverse display
Press the UP or DOWN button to select reverse display.
Press the SET button to set. Return to function selection mode.
[F13] Setting for reverse display mode completed
: When reverse display function is ON, the characters of the sub display appear upside down.
