-52-
No.PF※※-OMY0005
■[F16] Measurement display setting
Display/hide the measured accumulated flow rate, pressure, and temperature can be set.
<Operation>
Display [F16] by pressing UP or DOWN button in function selection mode.
Press the SET button. Move on to measurement display setting.
Measurement display setting
Press the UP or DOWN button to select the measurement display setting.
1) Pressure
Press the SET button to set.
2) Temperature
Press the SET button to set.
3) Accumulated flow
Press the SET button to set. Return to function selection mode.
[F16] Setting of measurement display completed
: When the temperature is set to “hide” and the integrated flow rate is set to “display”, the maximum number of display digits for the
accumulated flow rate is 9 digits.
