[Window comparator mode]
The Flow switch turns on within a set flow range (from [P1L]/[P2L] to [P1H]/[P2H]).
Set [P1L]/[P2L] (the lower limit of the switch operation), [P1H]/[P2H] (the upper limit of the switch
operation) and [WH1]/[WH2] (hysteresis), referring to setting method of page 27)
(When reversed output is selected, the main screen displays [n1L]/[n2L] and [n1H]/[n2H].)
[Accumulated output mode]
Set each [P1]/[P2] (set value), referring to setting method of page 27.
(When reversed output is selected, the main screen displays [n1]/[n2]).
Refer to the "switch output modes" for the relationship between the set values and operation (page 37).
 Setting of the normal/reverse output switching and hysteresis/window comparator mode/delay time/accumulated output mode
switching are performed using the function selection mode [F 1] OUT1 setting and [F 2] OUT2 setting.
