EUROSMC, S.A.
Polígono Industrial P-29, Calle Buril, 69.
28400 Collado-Villalba. Madrid (Spain).
Tels: 34 - 91 - 849 89 80*. Fax: 34 - 91 - 851 25 53
www.eurosmc.com • e-mail: sales@eurosmc.com
DISTRIBUTED BY:
Please Note: Due to the continuous research and development by EUROSMC, specifications in this catalog may be changed without previous notice.
TECHNICAL SPECIFICATIONS
MEASUREMENTS
TIME MEASUREMENT AND GRAPHIC REPRESENTATION
RANGES: Selectable between 100 ms, 200 ms, 400 ms, 800 ms and 2000 ms
RESOLUTION: ± 0.1 ms (sampling frequency of 10 kHz)
ACCURACY: ± 0.05% ±0.1 ms
GRAPHIC
REPRESENTATION
RESOLUTION: 0.8 ms per mm
CURRENT MEASUREMENT AND GRAPHIC REPRESENTATION
RANGE: 0 – 50 A DC
RESOLUTION: 0.1 A (sampling frequency of 1 kHz)
ACCURACY: 1% of the range ±100 mA
GRAPHIC
REPRESENTATION
RESOLUTION: Automatic scale up to 50 mA per mm (vertical)
CONTACT RESISTANCE MEASUREMENT
RANGES: Automatic range selection from 100.0 µΩ to 1.000 Ω
RESOLUTION: 0.1 µΩ maximum
ACCURACY: ± 1% of the range ± 1 digit
TESTING CURRENT: 10 A DC maximum
OPERATING SEQUENCES AND TIMING
AVAILABLE OPERATING SEQUENCES
Closing (C)
Opening (O)
Closing-Opening (C–O)
CAN BE:
Opening-Closing (O– C)
SELECTED BETWEEN
Closing-Opening-Closing (C–O–C)
Opening-Closing-Opening (O–C–O)
STARTING TIME SIGNAL
Coil operation
CAN BE SELECTED BETWEEN: Activation or de-activation or auxiliary input 1
Activation or de-activation or auxiliary input 2
TIMING DURATIONS
CLOSING ORDER: From 10 ms to 2000 ms (10 ms resolution)
OPENING ORDER: From 10 ms to 2000 ms (10 ms resolution)
INTERVAL 1: From 10 ms to 2000 ms (10 ms resolution)
INTERVAL 2: From 10 ms to 2000 ms (10 ms resolution)
TOUCH SCREEN PANEL, PRINTER AND MEMORY
GRAPHIC TOUCH SCREEN
TYPE: Transflective LCD
DIMENSIONS: 113 x 61 cm
COLOR: Black and white
CONTRAST: Adjustable
ILLUMINATION: CCFL
BUILT IN PRINTER
TYPE: Thermal
PAPER WIDTH: 110 mm (standard)
MAXIMUM DIAMETER OF PAPER ROLL: 40 mm
MEMORY
INTERNAL MEMORY: Stores up to 60 test results
INPUTS
MAIN CONTACT INPUTS
NUMBER: 3 inputs + common (ground)
OPEN CIRCUIT VOLTAGE: 10 V DC maximum
TESTING CURRENT: 100 mA maximum
STATES: Closed (C) (r<30Ω)
Preinsertion ( R ) (30Ω < r < 10kΩ)
Open ( O ) (r>10kΩ)
AUXILIARY INPUTS
NUMBER: 2 isolated binary inputs
CONTACT MODE: Open circuit voltage: 5 V DC
Testing current: 20 mA maximum
VOLTAGE MODE: Range: From ±1.5 to ±360 V DC
Low activation mode (Low) ±1.5 V DC
High activation mode (High) ±15 V DC
GENERAL
POWER SUPPLY
VOLTAGE SUPPLY: 100 to 240 V AC 50-60 Hz
INTERNAL BATTERY: MiMH Type 12 V DC
NORMAL OPERATING TIME: 10 hours
BATTERY RECHARGE TIME: 4.5 hours
DIMENSIONS: Heigth: 340 mm/Width: 300 mm/Depth: 150 mm
14” 12” 6”
WEIGHT: 8 kg. - 17.6 lb.
WORKING TEMPERATURE: 0º - 55º C
STORAGE TEMPERATURE: -40º / +70º C
HUMIDITY: Up to 95% (non condensing)
LANGUAGES INCORPORATED: English, Spanish, French, and German
(other languages upon request)
STANDARD ACCESSORIES INCLUDED
Download software EuroBreaker Basic
Instruction manual
1 voltage supply cable, shuko type 2.5 m
1 coil test lead cable
1 auxillary input test lead cable
1 contact measurement test lead cable
1 contact resistance measurement test lead cable
Nylon protective bag
