P
ROTOCOL
R
ELATED
C
ONFIGURATION
M
ENU
4-55
Setting the State Activity
Use the State Activity page to set the port members to actively or passively
initiate an LACP trunk.
Field Attributes
• Port – Lists all ports that can be configured as LACP trunk members.
• State Activity
- Active – A port can automatically initiate a trunk if an LACP partner
is detected at the other end of the link.
- Passive – A port can only create a trunk if an LACP partner at the
other end of the link sends a request to initiate the trunk.
Console – Click Protocol Related Configuration
=>
LACP
=>
State Activity.
Specify the ports which can actively initiate an LACP trunk, and save your
settings.
Tiger Switch 10/100 6709FL2 : LACP Port State Active Configuration
===========================
Port State Activity
---------------------------
1 Passive
2 Passive
3 Passive
4 Passive
5 Passive
6 Active
7 Passive
8 Active
actions-> <Edit> <Save> <Quit>
Select the action menu.
Tab=Next Item BackSpace=Previous Item Quit=Previous Menu Enter=Select Item
