C
ONSOLE
I
NTERFACE
4-10
Switch Static Configuration Menu
Use the Switch Static Configuration menu to configure the items listed in
the following table.
Tiger Switch 10/100 6709FL2 : Switch Configuration
===========================
Administration Configuration
Port/Trunk Configuration
Port Mirroring Configuration
VLAN Configuration
Priority Configuration
MAC Address Configuration
Misc Configuration
Main Menu
Configure the system,IP,and password.
Tab=Next Item BackSpace=Previous Item Enter=Select Item
Menu Description Page
Administration
Configuration
Configures device information, IP address,
user name and password
4-11
Port/Trunk
Configuration
Configures connection settings including
speed, duplex mode, and flow control;
also assigns ports to trunks
4-16
Port Mirroring
Configuration
Sets the source and target ports for mirroring 4-18
VLAN Configuration Sets VLAN groups and ingress filtering 4-20
Priority Configuration Assigns priority tagged frames to high or low
queue; sets the service method to a specified
ratio, high before low, or first-in first-out
4-26
