I
NITIAL
C
ONFIGURATION
2-6
To assign an IP address to the switch, complete the following steps:
1. Navigate from the Main Menu to –
Switch Static Configuration,
Administration Configuration, and then
IP Configuration.
2. Select <Edit>, type in the IP Address, Subnet Mask, and Gateway.
Press <Enter> after each item. Press <Ctrl-A> to return to the action
bar at the bottom of the screen. Select <Save> and press any key to
continue. (The IP addresses shown below are merely examples.)
3. Navigate back to the Main Menu, go to Reboot Switch menu, select
the “Restart” command, and press <Enter>.
Tiger Switch 10/100 6709FL2 : IP Configuration
===========================
IP Address : 192.168.16.1
Subnet Mask : 255.255.255.0
Gateway : 192.168.16.254
actions-> <Edit> <Save> <Quit>
Select the action menu.
Tab=Next Item BackSpace=Previous Item Quit=Previous menu Enter=Select Item
