S
WITCH
S
TATIC
C
ONFIGURATION
M
ENU
4-19
Field Attributes
Monitoring enable – Enables/disables port mirroring.
Monitoring Port – The port that mirrors traffic from the source port.
Monitored Ports – The ports whose traffic will be monitored.
Type – Shows port type (page 4-7).
Action – Mirrors specified traffic. (Range: RX, TX, Both, none)
Console – Click Switch Static Configuration
=>
Port Mirroring
Configuration. Enable monitoring, specify the monitoring (or analysis)
port, the monitor ports and traffic types to mirror, then save your settings.
Tiger Switch 10/100 6709FL2 : Port Monitoring Configuration
===========================
Monitoring enable :YES
Monitoring Port :5
Monitored Port :
Port Type Action
------------------------------------------
1. 10/100TX
2. 10/100TX
3. 10/100TX
4. 10/100TX
5. 10/100TX
7. 10/100TX RX
Trk1. 10/100TX
actions-> <Quit> <Edit> <Save>
Save successfully!Press any key to return!
Tab=Next Item BackSpace=Previous Item Quit=Previous Menu Enter=Select Item
