Page #92 background imageLoading...
Page #92 background image
C
ONSOLE
I
NTERFACE
4-24
Console – Click Switch Static Configuration
=>
VLAN Configuration
=>
VLAN Configure. Set VLAN Mode to “802.1Q” or “802.1QwithGVRP.
Set the PVID and Ingress Filtering rules, and save your settings.
Click Switch Static Configuration
=>
VLAN Configuration
=>
Create a
VLAN Group. Enter the VLAN Name (1-15 characters) and Group ID
(2-4094). Select a protocol type if you want to create a protocol based
VLAN. Use the Space bar to set each port to transmit tagged or untagged
frames, then save your settings.
Tiger Switch 10/100 6709FL2 : VLAN Support Configuraton
===========================
VLAN Mode :802.1Q
IngressFilter1 IngressFilter2
Port PVID NonMember Pkt Untagged Pkt
-------------------------------------------------------
1. 1 Enable Disable
2. 1 Enable Disable
3. 1 Enable Disable
4. 1 Enable Disable
5. 1 Enable Disable
6. 1 Enable Disable
7. 1 Enable Disable
8. 1 Enable Disable
9. 1 Enable Disable
actions-> <Quit> <Edit> <Save>
Select the Action menu.
Tab=Next Item BackSpace=Previous Item Quit=Previous Menu Enter=Select Item
