Smeg CWC620D - 4 Instructions for Technical Staff; Plumbing Hookup


‐CW620/630

8
C
SOLENOIDVALVE
Q
EARTHTERMINAL
E
ELECTRICITYSUPPLYCABLE
D
PERISTALTICHOSES
S
DRAINHOSE

4 INSTRUCTIONS FOR TECHNICAL STAFF
4.1 Plumbinghookup

Watersupplyanddrainhookup
Thewaterpipelinesandelectricitysupplycableleadoutofthebottomright‐
handcorneroftheappliance.Connectthewaterintakehosetoaconnector
with ¾” gas threaded fitting, fitting the filter A provided (in models with
Aquastop,thefilterandring‐nutformasingleunit).
Theconnectiontothewatermainsmustonlybemadewithnewhoses;the
useofoldorwornhosesisnotpermitted.
The dynamic water supply pressure must be between 1 and 6 bar; if it is higher, installation of a
pressurereducerisnecessary.
Itisessentialtofitamainstoptaponthewaterintakedeliverpipeline;thetapmustbeaccessible
after installation of the appliance, so do
 not install it behind the dishwasher. The stated cycle
duration applies to appliances supplied with hot water >50°C<60°C. If the dishwasher is supplied
withcoldwater,thecycledurationmightincreasedependingontheintakewatertemperature.The
dishwasherisfittedwithadrainpumpandcanoperatewithdrain
connectionsonthefloororwall.
