5 FIRST START-UP
Firststart‐up
The electrical protection system must undergo a functional test before the appliance is put into
operation.
Theappliancemustbe installedand/orinspectedbyqualifiedstaff,whowillstartitupforthefirst
timeandprovidetherelevantoperatinginstructions.


Preparingforuse(important)
Therinseaiddispenserisfittedonallmodels,thedetergentdispenseronlyonsome.
If both dispensers are present put the external detergent and rinse aid containers in place and
inserttherespectiveintakehosesontherearoftheapplianceintothem.
Redhose:detergent
bluehose:rinseaid



Beforeinsertingthehosesintothecontainers,fittheweights(needed
toensurethattheyalwaysdrawinliquidfromthebottomsofthe
containers)andthefiltersontotheirendsasshown.
Ifthedetergentdispenserisnotfactory‐fitted,itcanberetrofitted
afterorderingtherelativekit.


Asanalternativeanexternaldispensercanbefitted,makingthe electricalconnectionbymeansof
anH05RN‐F2x0.5 mmelectricalcable,which canbelaidalongthe routeshown intheTECHNICAL
DATA diagram. The electrical connection must be made in accordance with the electrical system
diagram
suppliedwiththedishwasher, disconnectingtheinternaldispenser,ifany,and makingthe
connectiontotheexternalunit.
Thedispensermustoperateon230V/50Hzwithmaximumpowerabsorptionof15W.
Connecttothedetergentdispenseroutsidethedishwasherusingtheredhosementionedabove.


Asanalternativean
externaldispensercanbefitted,makingtheelectricalconnectionby meansof
anH05RN‐F2x0.5 mmelectricalcable,which canbelaidalongthe routeshown intheTECHNICAL
DATAdiagramandconnectedasshowninthewiringdiagramsuppliedwiththedishwasher.
Thedispensermustoperateon230V/50Hzwithmaximumpowerabsorptionof15W.
Connecttothedetergentdispenseroutsidethedishwasherusingtheredhosementionedabove.

