Chapter 3 - Information o n the machine
20
Translation from the original
ATTENTION!
Leave the hood open when the machine is switched off to allow it to cool down.
Near some zones of the machine, some pictograms were placed in order to recall the attention
of the operator concerning the precautions required to avoid dangers. In order to have greater
understanding of the symbols used, the main ones are described hereafter.
3.3 IDENTIFICATION DATA AND TECHNICAL DATA OF THE
MACHINE
Each machine is provided with a plate where it is easy to recover data which must be
communicated to the manufacturer in case of problems or when requesting spare parts etc.
(ref. 1-2-3-4). This plate also carries electrical technical data for installation of the machine (ref.
a-b-c-d).
1 - Model
2 - Serial number
3 - Machine code
4 - Year of manufacture
a - Nominal voltage
b - Nominal frequency
c - Nominal power
d - Nominal current
ATTENTION! Before performing connections to the electrical mains, make sure that the power
supply voltage is compatible with that shown on the plate.
DANGER DUE TO THE HIGH VOLTAGE ZONE WITH RISK OF
ELECTROCUTION INSIDE ELECTRICAL CONTROL BOARD
BURNING DANGER DUE TO CONTACT WITH HIGH
TEMPERATURE SURFACES
CRUSHING DANGER
CUTTING DANGER - PAY ATTENTION TO YOUR HANDS
