2. Tunnel installation
2.3 WEIGHT AND DIMENSIONS OF THE PACKED TUNNEL
2.4 WEIGHT AND DIMENSIONS OF THE TUNNEL
2.5 TRANSPORT AND UNPACKING
Fig. 2.3.1
T450 T650E T650EF T650 T650F
X
1420
mm
1415
mm
1845
mm
2280
mm
2280
mm
Y
1030
mm
1220
mm
1220
mm
1220
mm
1220
mm
Z
1555
mm
1725
mm
1725
mm
1725
mm
1725
mm
WEIGHT
Kg.
223 315 350 450 470
Y
Z
X
Fig. 2.4.1
T450 T650E T650EF T650 T650F
X
1310
mm
1316
mm
1749
mm
1846
mm
2285
mm
Y
933
mm
1147
mm
1147
mm
1147
mm
1162
mm
Z
1439
mm
1615
mm
1570
1630
1615
mm
1570
1630
W
500
mm
1010
mm
WEIGHT
Kg.
187 241 276 350 375
W
X
Y
Z
SMIPACK S.p.A. in function of the means of
transport and of the type of products to be
shipped utilizes packagings adequate to
guarantee the integrity and preservation
during transportation. It is recommended to
handle with great care the machine during
transport and positioning. The forwarder is
responsible for every damage that may
occur during transport. Unpack the unit
making sure not to damage any exposed
parts.
