Vega 30 Router User Manual Explanation of Safety Symbols Safety 2.1
Issue1 Revision 1 Page 11 © 2017 SAM
2.1 Explanation of Safety Symbols
2.2 Safety Warnings
CAUTION: These servicing instructions are for use by qualified personnel only. To reduce the
risk of electric shock, do not perform any servicing other than that contained in the Operating
Instructions unless you are qualified to do so. Refer all servicing to qualified service
personnel.
2.3 Mains Power Supplies
The Vega 30 Router chassis has two DC power connectors, for up to two separate external
Vega 30 power supply modules; these modules each have an IEC mains power socket.
The mains supply voltage will be auto-detected by the external power supply modules,
provided it is in the range 100 - 240 Vac and 50 / 60 Hz.
Always ensure that the unit is properly earthed and power connections are correctly made.
This Vega 30 equipment with its separate external power supply modules must be supplied
from a power supply system providing a PROTECTIVE EARTH connection and having a
neutral connection which can be reliably identified.
The power circuit breakers or switches supplying power to the unit should be close to the unit
and easily accessible.
This symbol refers the user to important information contained in the accompanying
literature.
This symbol indicates that hazardous voltages are present inside. No user serviceable
parts are inside. This system should only be serviced by trained personnel.
To reduce the risk of electric shock, do not expose this appliance to rain or moisture.
The installation and maintenance of the Vega 10 Series router(s) and any associated
equipment must be carried out by persons qualified to work with equipment which may be
connected to a mains electric supply.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVERS
NO USER SERVICABLE PARTS
REFER SERVICING TO QUALIFIED
PERSONNEL ONLY
