Vega 30 Router User Manual Direct Video - Routing Template Vega 30 RollCall Templates 7.11

7.11 Direct Video - Routing Template

The Direct Video routing template controls the Vega 30 Router’s video crosspoint.

The Direct Video routing template screen operation is similar to the one described in Section

7.9 “Assoc Routing - Routing Template” on page 148.

Figure 116 (Direct Video) Routing Template

Take buttonVideo Sources Video Destinations
