Vega 30 Router User Manual Order Codes Product Overview 3.2
Issue1 Revision 1 Page 16 © 2017 SAM
3.2 Order Codes
3.3 Options
The basic Vega 30 Router is a 34x34 SDI video-only router with timed-switching. It routes
video and embedded audio. Licensable options are available to add audio routing and add
processing on outputs. See Table 2.
Order Code Description
Vega 30 Router:
VG30 Vega 30 Router (34x34 video) with single PSU.
VG30-PSU Vega 30 Power Supply Unit (Second, redundant)
VG30-P2 Router package:
Vega 30 Router (34x34 video) with single PSU
+ 12 Clean & Quiet Switching outputs.
(VG30 + VG10-CSA + VG10-AR)
License Options:
VG10-CSA Enable Line Sync and Clean Switching on outputs 1-12
(and Quiet Switching with option VG10-AR)
VG10-CSB Enable Line Sync and Clean Switching on outputs 13-24
(and Quiet Switching with option VG10-AR)
VG10-CSC Enable Line Sync and Clean Switching on outputs 25-34
(and Quiet Switching with option VG10-AR)
VG10-AR Enable Audio Routing, Audio embed/de-embed, and MADI inputs and
outputs. Quiet switching at outputs (with a VG10-CSx license).
Spares:
VG30-PSU Vega 30 Power Supply Unit (Main or redundant)
VG30-FAN Vega 30 Replacement Fan Assembly
Table 1 Vega 30 Router Order Codes
Option
SDI Video
34x34
Router
Number
of PSUs
Video SDI Outputs MADI
Inputs and
Outputs
Audio
Routing
Audio
Embed/
De-embed
1 to 12 13 to 24 25 to 34
Basic Router:
VG30
Yes 1 TS TS TS No No No
Options:
VG30-PSU
1- - - ---
VG10-CSA
-LS, CS- - ---
VG10-CSB
--LS, CS - ---
VG10-CSC
-- -LS, CS ---
VG10-AR
-QS
See Note 1
QS
See Note 1
QS
See Note 1
Yes Yes Yes
Where: TS - Timed switching;
LS - Line Sync on output;
CS - Clean switching at output;
QS - Quiet switching at output.
Note 1: Quiet switching at outputs requires VG10-AR option and one or more VG10-CSx options.
Table 2 Features of the Vega 30 Router Options
