Vega 30 Router User Manual Signal Inputs Specifications A.5
Issue1 Revision 1 Page 242 © 2017 SAM
A.4.2 Vega 30 Power Supply Modules
A.5 Signal Inputs
A.6 Signal Outputs
AC Inlet
AC Inlet Connector IEC 320-C14
Voltage 100 to 240 V ac, 50 / 60 Hz
Current Max. 2 A
Fuses
Vega 30 PSU Module None.
DC Output
DC Output Connector 4-way mini-DIN
Voltage 12 V dc
Current Min. 8.33 A
Video Inputs
Number and Type 34-off. HD-BNC
Impedance 75 R
Amplitude 800 mV nominal
DC offset <5 V
Return loss >15 dB: 10 MHz to 1.5 GHz
>10 dB: 1.5 GHz to 3.0 GHz
Cable equalization Automatic.
For Belden 1694A:
SD: 350 m (1150 ft)
HD: 200 m (650 ft)
3G: 140 m (460 ft)
Standards SD-SDI/ HD-SDI/ 3G-SDI:
• SD-SDI @ 525i59.94 & 625i50
• HD-SDI @ 720p50, 720p59.94& 720p60
• HD-SDI @ 1080i50, 1080i59.95 & 1080i60
• 3G-SDI @ 1080p50, 1080p59.94 & 1080p60
UHD support via Quad 3G-SDI.
Other standards (not including DVB-ASI) will pass.
MADI Audio Inputs
Number and Type 3-off. HD-BNC
Impedance 75 R
Signals MADI to AES-10
48 kHz sampling rate.
56 or 64 channel modes.
Video Outputs
Number and Type 34-off. HD-BNC
