Vega 30 Router User Manual Environmental Considerations Installation 5.1
Issue1 Revision 1 Page 41 © 2017 SAM
5 Installation
5.1 Environmental Considerations
The ambient temperature for all the supplied equipment should not exceed the limits specified
in Appendix A “Physical” on page 241.
Installing the equipment in a clean environment with moderate temperature and humidity will
promote a long and trouble-free equipment life.
5.2 Chassis Dimensions
The chassis is a shallow 3RU unit. Dimensions are shown in Figure 20:
• Refer to safety information in Section 2 “Safety” on page 8 Section 2 “Safety” on
page 8
• The installation and maintenance of the Vega 10 Series router(s) and any
associated equipment must be carried out by persons qualified to work with
equipment which may be connected to a mains electric supply.
• The mounting and installation of the equipment must be arranged by the user to
comply with all safety regulations of the indigenous authority.
Figure 20 Vega 30 Dimensions
Dimensions are in millimeters [inches]
