23
5.3.11 Add Device Information
Clip , add device information;
Clip , enter device information
setting interface, can choose device name and
device SN No.
Device name can be defined by entering 2.4.5
user management, device SN No. cannot be
changed.
5.3.12 Add String
Clip to add string.
Clip to enter the string setting
interface. The system default can add 5
different strings. One data allows maximum 20
string objects, each string of character
maximum number is 75.
Note: when add one same string object, other
same strings will be modified automatically
while modify one of string.
