sol-ark 15K - Page 13

Sol-Ark Battery Integration Guide | SK140-0026-005 9
Table IV: Pin Configurations of “RJ45” and “RJ45_CAN” ports for ModBus and CANBus protocols
Pin
RJ45_485 (Modbus)
RJ45_CAN (CANBus)
1
RS-485 B-
--
2
RS-485 A+
3
GND
GND
4
--
CAN Hi
5
--
CAN Lo
6
GND
GND
7
RS485 A+
--
8
RS485 B-
--
