NOTE
Only the first and last SolarEdge devices in the chain should be terminated.
The other inverters in the chain should have the termination switch OFF
(down position).
11. If not using surge protection, connect the grounding wire to the first inverter in the
RS485 chain; make sure the grounding wire is not in contact with other wires. For
inverters with a Connection Unit, connect the grounding wire to the grounding bus-
bar in the Connection Unit.

Verifying the Connection
After connecting and configuring a communication option, perform the following
steps to check that the connection to the monitoring server has been successfully
established.
1.
Go to Commissioning >Status.
2. In the Summary section, under Server Comm., make sure S_OK is displayed
together with the selected communication option.
3.
Scroll down to the Communication section and check that the communication
options are as required.
EV Charging Single Phase Inverter Guide MAN-01-00583-1.5
60 Verifying the Connection

SolarEdge SE5000H Specifications

General

Model	SE5000H
Manufacturer	SolarEdge
Topology	Transformerless
AC Nominal Power	5000 W
Rated AC Power	5000 W
Cooling	Natural Convection
Noise Level	< 25 dBA
Protection Rating	IP65
Max. Input DC Voltage	480 Vdc
Number of MPP Trackers	1
AC Voltage	240 V
Weight	10.6 kg
Operating Temperature Range	-25°C to 60°C
