7828 Density Transmitter Technical Manual Mechanical Installation
78285000_AB 2-5
Top or Plan view
2”Schedule 40
Pocket or “T”
From this, it would appear that almost every installation requires a separate in situ
calibration - a very undesirable situation. The problem is resolved by providing standard
calibration geometries which can be used in all pipe work configurations and thereby allow
the factory calibration conditions to be reproduced in the process. These standard
geometries are described in section 2.3.
