6.3.6 Sonic 150C IEC Retro Kit
Item
Part No.
Description
Qty.
No.
132
Frame
160
Frame
1
(Not Supplied)
2
14459
Blower Head, Sonic 150C
1
3
13007
13028
Bracket, Sonic 150 IEC
1
4
13455
Belt Tensioner Assembly
1
5
13450
Pulley, Blower
1
6
13452
Pulley, Motor
1
7
Section 6.4.3
IEC Bushing Kit
1
8
Section 6.5
Belt
1
9
11130
Belt Guard
1
10
11934
Vibration Isolators
4
11
10653
Uni-mounts
2
12
Feed thru Assembly – Water Cooled
1
13
15018
Retainer – Blower Pulley
1
14
13506
Standoff Assembly
2
15
10337
10338
Spacer, IEC Motor
1
16
10454
Screw, 5/16-18 x 1.0 Lg. SHCS SS
8
17
13482
Screw, 5/16-24 x 1.0 Lg. FHCS SS
1
18
12342
Nut, 5/16-18 Hex SS w/ Nylock
2
19
13573
Screw, 3/8-16 x 1.5 Lg. SHCS (See Bushing Kit)
3
20
12653
Screw, M8 x 40mm Lg. HHC Plated
4
20a
12654
Screw, M12 x 40mm Lg. HHC Plated
4
21
12340
Screw, 5/16-18 x 1.5 Lg. FHS SS
1
22
11251
Washer, 3/8” Flat Plated
8
23
11407
Lock Washer, 3/8” Plated
8
24
10273
Nut, 3/8-16 Hex Plated
8
25
12767
Washer, M8 Plated
4
25a
12770
Washer, M12 Plated
4
26
12766
Lock Washer, M8 Plated
4
26a
12771
Lock Washer, M12 Plated
4
