6.3.7 Sonic 150 Upgrade Kit
Item
Part No.
Description
Qty.
No.
215TC &
256TC
Frame
284TSC
Frame
(Only)
2
14458
Blower Head, Sonic 150
1
3
12335
12623
Bracket, Sonic 150
1
4
13455
Belt Tensioner Assembly
1
5
13450
Pulley, Blower
1
6
13452
Pulley, Motor
1
8
Section 6.5
Belt
1
9
N/A
12615
Belt Guard
1
13
15018
Retainer – Blower Pulley
1
14
13506
Standoff Assembly
2
16
10454
Screw, 5/16-18 x 1.0 Lg. SHCS SS
8
17
13482
Screw, 5/16-24 x 1.0 Lg. FHCS SS
1
18
12342
Nut, 5/16-18 Hex SS w/ Nylock
2
6.3.8 Sonic 150C Upgrade Kit
Item
Part No.
Description
Qty.
No.
215TC &
256TC
Frame
284TSC
Frame
(Only)
2
14459
Blower Head, Sonic 150C
1
3
12335
12623
Bracket, Sonic 150
1
4
13455
Belt Tensioner Assembly
1
5
13450
Pulley, Blower
1
6
13452
Pulley, Motor
1
8
Section 6.5
Belt
1
9
N/A
12615
Belt Guard
1
12
Feed thru Assembly – Water Cooled
2
13
15018
Retainer – Blower Pulley
1
14
13506
Standoff Assembly
2
16
10454
Screw, 5/16-18 x 1.0 Lg. SHCS SS
8
17
13482
Screw, 5/16-24 x 1.0 Lg. FHCS SS
1
18
12342
Nut, 5/16-18 Hex SS w/ Nylock
2
