Sonoscape S6 Service Manual

S6 Portable Digital Color Doppler Ultrasound System
Service Manual
Rear View
1
2
3
4
5
6
7
8
9
1 Probe Connection Port 1 6 ECG Port
2 Probe Connection Port 2 7 Equipotential point (earth)
3 Video Printer Controller Port 8 Power Switch
4 Foot Switch Socket 9 Power Input Socket
5 Video Out
3.3 Applications
The S6 system, with a wide range of probes available, is extremely versa-
tile. This section introduces the applications that the S6 system is suitable
for.
6 Small organs (breast, thyroid, testicle and etc.)
6 Vascular
6 Abdomen (liver, spleen, cholecyst, kidney and etc.)
6 Obstetric
P/N: 4720-0034-01A
3-4
