S6
P
or
table
Digital
Color
Doppler
Ultrasound
System
Service
Manual
5.2
Back
Cover
1
2
3
4
5
6
Item
Description
Quantity
1
∼
6
M3
×
6
screws
6
Instructions
Note:
Screws
1
∼
4
are
covered
by
rubbers.
Y
ou
need
tweezers
to
remove
them
before
removing
the
screws.
R
emove
all
the
6
screws
shown
in
the
above.
Continued
on
next
page
.
.
.
P/N:
4720-0034-01A
5-4
33
35
