S6 Portable Digital Color Doppler Ultrasound System
Service Manual
4.6 Part List
Part No. Name
Quantity
Description
7500-0826 MPC
1
Probe connection PCB board
7500-0820 DBTR
1
Emission/Reception PCB board
7500-0821 DBF
1
PCB board for receiving digital
beam forming and signal pro-
cessing
7500-0822 DBHV
1
PCB board providing high volt-
ages
7500-0815 KBD
1
Keyboard PCB board
7500-3039 KEAA
1
KEAA board serves as a hub
for interconnecting other PCB
boards.
2101-0008 PC Motherboard
1
It is the central control unit for
data processing and video/audio
output.
2101-0152 HDD
1
160G hard disk drive
3900-0012 LCD Monitor
1
Designed exclusively for medical
use
NA
Voltage Inversion
Board
1
Provides high voltage source for
LCD.
P/N: 4720-0034-01A
4-5
