<ta> Description

0-63 According to GSM 04.18 V8.6.0, the coding of the timing

advance value is the binary representation of the timing

advance in bit periods; 1 bit period = 48/13 ìs. <ta> is the

integer representation of the timing advance in binary

format

64-255 Reserved
