1. Mechanical Description
1.1 Interface Description
The pictures below show the mechanical design of the GM47 along
with the positions of the different connectors and mounting holes. The
GM47 is protected with AISI 304 stainless steel covers that meet the
environmental and EMC requirements.
Figure 1.1 GM47 viewed from below
Figure 1.2 GM47, viewed from above
Please note the following:
• Mounting holes positioned at the corners make it possible to
securely bolt the module into your application.
Mounting hole/ground connection
Antenna connector
System connector
