GM47/GM48 INTEGRATOR’S MANUAL

LZT 123 7263 R1A

Figure 1.4 Audio signals, connection and routing

Figure 1.5 Comms signals, connection and routing

J12

GM47

EAR

MIC

Handset

Buzzer

PCM

3.5mm socket

RJ11 connector

8 pin Mini-DIN

Selectable

Jumpers

ATMS

AFMS

MICN, MICP, BEARN, BEARP

Buzzer

PCM

(Audio out)

(Audio in)

J12

GM47

UART1 (EDB)

UART2 (ACB)

UART3

Selectable

jumpers

TD, RD, DTR, DCD,

RTS, CTS, RI

TD2, RD2 & SERVICE

TD3 & RD3

Level shifters
