Available Signal Formats
Appendixes
a: Signal can be reproduced.
a(2): Two adaptors are used.
*: Also compatible with 1/1.001.
**: 2048 × 1080 4:4:4 RGB format input signal is compatible with the input code 4-1019 (10bit) and 16-4079 (12bit).
DVI-D
Single-link 4:2:2 YPbPr 10bit
1920×1080/30*P
×××
a SMPTE-292M
Dual-link 4:4:4
YPbPr 10bit
×××
a(2) SMPTE-372M
RGB 10bit
YPbPr 12bit
RGB 12bit
Single-link 4:2:2 YPbPr 10bit
1920×1080/50i
×××
a SMPTE-292M
Dual-link 4:4:4
YPbPr 10bit
×××
a(2) SMPTE-372M
RGB 10bit
YPbPr 12bit
RGB 12bit
Single-link 4:2:2 YPbPr 10bit
1920×1080/60*i
×××
a SMPTE-292M
Dual-link 4:4:4
YPbPr 10bit
×××
a(2)
SMPTE-372M
RGB 10bit
YPbPr 12bit
RGB 12bit
Dual-link 4:2:2 YPbPr 10bit 1920×1080/50P
×××a(2)
Dual-link 4:2:2 YPbPr 10bit 1920×1080/60*P
×××a(2)
Single-link 4:2:2 YPbPr 10bit 1280×720/24*P
×××a
SMPTE-292M
Single-link 4:2:2 YPbPr 10bit 1280×720/25P
×××a
Single-link 4:2:2 YPbPr 10bit 1280×720/30*P
×××a
Single-link 4:2:2 YPbPr 10bit 1280×720/50P
×××a
Single-link 4:2:2 YPbPr 10bit 1280×720/60*P
×××a
Dual-link 4:4:4
RGB
10bit**
2048×1080/24*PsF ×××a(2) 12bit**
XYZ 12bit
Dual-link 4:4:4
RGB
10bit**
2048×1080/24*P ×××a(2) 12bit**
XYZ 12bit
Signal format System
Interface
sampling
frequency
[MHz]
Aspect
ratio
Standard
DVI Video
Single-link 4:4:4 RGB 8bit 640 × 480/60*P 25.200* 4:3
CEA-861Single-link 4:4:4 RGB 8bit 720 × 480/60*P 27.027* 4:3/16:9
Single-link 4:4:4 RGB 8bit 1280 × 720/60*P 74.250* 16:9
Single-link 4:4:4 RGB 8bit 1920 × 1080/60*i 74.250*
16:9 CEA-861
2.39:1
Signal format Applied system
BKM-
220D
BKM-
227W
BKM-
229X
BKM-
243HS/
244CC
Standard
