Sony BVM-L230 - Input Configuration Menu; Overview; Menu Function and Operation

50
Input Configuration Menu
Chapter 3 Menu
Input Configuration Menu
Overview
This menu is used for pertaining data to the input signals.
When Input Configuration is selected, the following menus are displayed.
The current channel is displayed. Perform the input setting
for the selected channel.
Before setting
Set the input signal for each channel. A channel number (1
to 30) is entered with the numeric buttons (page 35).
This menu is not selectable in the following cases:
• When Side by Side is set to On
• When Wipe is set to On
• When Butterfly is set to On
• When Blending is set to On
Menu Function and Operation
iInput Configuration 1/2
CH01
Format B xxxxx
Slot No: xxxxx
Input No: xxxxx
Screen Aspect B
Sync Mode: xxx
Color Temp: xxx
Picture Preset: xxxxx
Matrix/Gamma B
v
V
iInput Configuration 2/2
CH01
H Shift Offset: xxx
Channel Name B
NTSC Setup Level:: xx
Component Level: xxxxx
Betacam Setup Level:: xxx
RGB Range: B
1080I/PsF B
Film Cadence:: xxx
Copy From B
v
V
Note
Menu Function and operation ([ ]: factory setting)
Format Sets the input signal type.
Note
The default setting is HD-SDI/D1 Auto. Set Format except for when the BKM-243HS or BKM-
244CC is installed.
SDI/HD-SDI Sets the serial digital signal format (SDI or Single-link HD-SDI) when BKM-220D, BKM-
243HS or BKM-244CC is installed.
When BKM-220D is installed
D1
When BKM-243HS or BKM-244CC is installed
[HD-SDI/D1 Auto]: Changes the format automatically according to the format of the
input signal.
D1
Dual Link HD-SDI Sets the Dual-link HD-SDI signal format when two BKM-243HS or BKM-244CC are installed
in the OPTION 1 and 2 or OPTION 3 and 4 option slots.
4:2:2 YPbPr 10bit
4:4:4 YPbPr 10bit
4:4:4 RGB 10bit
4:4:4 YPbPr 12bit
4:4:4 RGB 12bit
4:4:4 XYZ 12bit
