96
Specifications
Appendixes
Appendixes
Specifications
General
LCD panel a-Si TFT Active Matrix
Picture size 22.5 inches
Display area 483.84 (H) × 302.4 (V)
Resolution 1920 (H) × 1200 (V) pixel
Backlight High-purity LEDs
Panel drive RGB 10 bit
Panel frame rate
96/100/120 Hz
Viewing angle 85º/85º/85º/85º
(up/down/left/right, contrast 10:1)
Pixel efficiency 99.99%
Warm-up time Approx. 30 minutes
Power consumption
Approx. 180 W (at maximum load, the
luminance compensation due to the
aged deterioration of the LED is
included.)
Approx. 130 W (the BKM-243HS is
attached, the default status)
Power requirements
100 to 240 V AC,
2.0 to 0.9 A, 50/60 Hz
Peak inrush current
(1) Power ON, current probe method:
20 A (100 V), 52 A (240V)
(2) Hot switching inrush current,
measured in accordance with
European standard EN55103-1: 25
A (230 V)
Mass Approx. 22 kg (48 lb 8 oz)
Input/Output
Option slot Four slots
Signal format
Refer to “Available Signal Systems”
(page 100) and “Available Signal
Formats” (page 102).
PC input DVI-D (HDCP correspondence) × 1
Signal format
Refer to “DVI-D” (page 104) of
“Available Signal Formats”.
Control OPTION A: Mini-DIN 8-pin (female) ×
1
OPTION B: USB (Type A) type × 1
LAN (10BASE-T/100BASE-TX): RJ-
45 × 1
PARALLEL REMOTE: D-sub 9-pin
(female) × 1
DC 5V OUT: Circle 4-pin (female) × 1
Picture performance
Normal scan 0% scan
Native scan Mapping the pixels of the signal to the
panel to one-to-one mode, or
displaying an SD signal of non-
square pixels (the number of H
pixels of the signal system is 720 or
1440) or a 640 × 480 SD signal of
DVI video by scaling processing of
doubling for the V direction and
correct aspect ratio for the H
direction and also optimizing and
displaying a picture by modifying
the aperture coefficient value, filter
coefficient value, etc.
Under scan 3% under scan
Over scan Mask of 5% over scan portion in the
normal scan
Color temperature
D56, D61, D65, D93, D-Cine*, (Setting
possible in other color temperature)
*D-Cine: x=0.314 y=0.351
Standard luminance
100 cd/m
2
(Preset1 to Preset5)
48 cd/m
2
(Preset (D-Cine))
(1.0 Vp-p reference signal, 100% white
signal input)
Color space (color gamut)
ITU-R BT.709, BVM EBU, BVM
SMPTE-C, D-Cine*
1
,
L230 Native*
2
,
S-GAMUT*
3
*1 Chromaticity point of SMPTE RP 431-
2 is not covered in full.
