Chapter 1 Overview
Options
For external control
BKM-16R Monitor Control Unit
The BKM-16R is a controller of the BVM-L230 and you
can control multiple monitors from one controller.
In this manual, the BKM-16R is referred to as the
controller.
For installation
BKM-37H Controller Attachment Stand
Used to join a BKM-16R and the BVM-L230.
When the stand is attached to the BVM-L230, you can
adjust the monitor angle up or down.
SMF-700 Monitor Interface Cable
Used to connect the BVM-L230 to the BKM-16R.
BKM-23M Monitor Protection Panel
The BKM-23M is a panel to protect the LCD panel of the
BVM-L230.
Input adaptors
The input connector panel is composed by installing the
optional input adaptor into the input option slot at the left
side of the monitor. Up to four adaptors can be installed to
the monitor.
The input signal type for each connector of the adaptor is
set with the Input Configuration menu, in accordance with
the configuration of the connector panel.
When installing the adaptor, be sure to perform the
necessary input signal setup with the Input Configuration
menu. If the setup is not performed, the adaptors may not
function correctly.
For information about the Input Configuration menu, see
page 50.
For details of each input adaptor, refer to the operating
instructions of each model.
BKM-220D SDI 4:2:2 Input Adaptor
Includes a decoder for serial digital signals (525/625
component). Input/output connectors for two serial digital
channels and output connector for one monitor channel are
equipped.
The signal from the MONITOR OUT connector of the
BKM-220D does not satisfy the ON-LINE signal
specifications.
BKM-227W NTSC/PAL Input Adaptor
Includes a decoder for NTSC/PAL/PAL-M/SECAM
signals. Input/output connectors for each one composite
signal channel and Y/C signal channel are equipped.
BKM-229X Analog Component Input Adaptor
Includes a decoder for analog component signals and
analog RGB signals. Input connector for one channel is
equipped.
BKM-243HS HD/D1-SDI Input Adaptor
Includes a decoder for serial digital component signals.
Input/output connectors for two serial digital channels and
output connector for one monitor channel are equipped.
The signal from the MONITOR OUT connector of the
BKM-243HS does not satisfy the ON-LINE signal
specifications.
BKM-244CC HD/SD-SDI Closed Caption
Adaptor
Includes a decoder for serial digital component signals.
EIA/CEA-608 or EIA/CEA-708 standard closed caption
signals superimposed on the SDI signals are decoded and
displayed. Input/output connectors for two serial digital
channels and output connector for one monitor channel are
equipped.
The signal from the MONITOR OUT connector of the
BKM-244CC does not satisfy the ON-LINE signal
specifications.
When you install the following input adaptors to this
equipment, use those with the serial numbers given below.
• BKM-220D with serial number 2100001 or higher
• BKM-229X with serial number 2200001 or higher
• BKM-243HS with serial number 2108355 or higher
BKM-220D: This equipment may not meet the
requirements of the electromagnetic interference standard
if designated input adaptors are not installed.
BKM-229X: This equipment may not work correctly or
you may not be satisfied with the performance if
designated input adaptors are not installed.
BKM-243HS: This equipment may not meet the
requirements of the electromagnetic interference standard
or work correctly, or you may not be satisfied with the
performance if designated input adaptors are not installed.
Note
Note
Note
Note
Caution
