58
Display Setting Menu
Chapter 3 Menu
User Matrix/Gamma
Copy From Copies the user data from the other Matrix/Gamma.
Preset Value Copies other data in this monitor.
When the item is selected, you can select from User1, User2, User3, User4 or User5.
Other Monitor Copies data from another monitor.
Monitor ID Enter the ID number of the source monitor.
When the NETWORK switch is set to PEER TO PEER, this is not selectable.
When the ID number is entered, you can select from User1, User2, User3, User4 or User5.
Memory Stick Copies data in the “Memory Stick”.
When the item is selected, the file names in the source “Memory Stick” are displayed.
When the file is selected, you can select from User1, User2, User3, User4 or User5.
Native Scan Mode Sets the native scan mode.
[Aspect Correction]: Displaying an SD signal of non-square pixels (the number of H
pixels of the signal system is 720 or 1440) or a 640 × 480 SD signal of DVI video by
scaling processing of doubling for the V direction and correct aspect ratio for the H
direction and also optimizing and displaying a picture by modifying the aperture
coefficient value, filter coefficient value, etc.
×1: Input signal display without conversion
×2: Input signal display doubled
For selecting Aspect Correction, ×1 or ×2, see “Picture Display Size” on page 107.
Notes
• When an HD signal or DVI computer signal is input, the signal is displayed in ×1 mode,
even if the mode is set to Aspect Correction or ×2.
• When an SD signal from the BKM-229X is input and the number of the H pixels of the
signal system is 1440, the signal is displayed in ×2 mode, even if the mode is set to ×1.
• When you select Aspect Correction and set Native Scan to On for SD signal input, Aperture
is set to On (factory setting).
Aperture Value Sets the aperture modification value.
Sets to 000 to 200.
[090] (when the signal is displayed in Aspect Correction mode of the native display), [000]
(when the signal is displayed in mode other than Aspect Correction of the native display)
NTSC Comb Filter Sets the type of NTSC filter.
You can select from [3Lines] or 3D.
When the BKM-227W is installed, you can select the item.
Filter Switch Sets whether or not to turn on the Y/C separation filter ([Off] or On) when the picture is set to
monochrome mode.
When the BKM-227W is installed, you can select the item.
Peak White Control When the brightness is increased, using the brightness adjustment, the picture may be
clipped, because of the dynamic range of the circuit. Sets whether or not to control the signal
gain automatically according to the setting value of the brightness, to prevent such clipping
(Off or [On]).
Note
Peak white control does not function with XYZ signals.
Menu Function and operation ([ ]: factory setting)
To Next Page
