CCD-TR315E/TR415E/TR425E/TR515E/TR516E/TR713E
CCD-TRV16E/TRV26E/TRV27E/TRV27EP/TRV36E/TRV46E
4-52
4-53 4-54
STEADY SHOT
SE-80/81
SE-80/81 (STEADY SHOT (STEADY SHOT MODEL)) PRINTED WIRING BOARD
– Ref No. SE-80 BOARD: 4,000 series, SE-81 BOARD: 9,000 series –
SE-80
SE-81BOARD
C451 C-7
C452 D-3
C453 B-7
C454 E-6
C455 C-3
C456 C-3
C457 C-2
C458 C-3
C459 C-7
C460 E-6
C461 C-6
C462 C-6
C463 C-3
C464 C-6
C465 C-3
C466 C-6
C467 A-2
C468 A-6
C469 A-2
C470 A-6
C471 B-3
CN451 A-3
D451 A-6
D452 A-6
IC451 C-6
J451 A-8
L451 B-3
L452 B-2
L453 A-3
L454 A-2
R451 C-6
R452 D-3
R453 D-3
R454 C-6
R455 D-7
R456 C-3
R457 C-3
R458 C-6
R459 C-6
R460 C-3
R461 C-6
R462 B-3
R463 B-3
SE451 B-3
SE452 E-3
• For Printed Wiring Boards.
• Chip diode
3
21
There are few cases that the part isn't mounted in this model is
printed on this diagram.
VF-99... B/W EVF models only
(B/W EVF)
PD-107... TRV series only
RGB decoder, LCD,
LCD drive, Back light
CF-61...
TRV series only
(Control)
SE-80...
TR713E only
SE-81... TRV series only
(Steady shot)
CD-210...
TR series only
CD-211... TRV series only
(CCD imager)
D451
O1ZB8.2(TPL3)
(TR 713E)
TRV SERIES:CCD-TRV16E/TRV26E/TRV27E/TRV27EP/TRV36E/TRV46E
STEADY SHOT MODEL:CCD-TR713E/TRV46E
(TRV SERIES)
(TRV SERIES)
CN451(TRV SERIES)
TRV46E
C467
C468
L453
0.001u
0.001u
100uH
XX
XX
0uH
A-7073-803-A
(AEP,UK,EE,NE,RU)
SE81(VMM CE)MOUNT
A-7073-810-A
(E,HK,AUS,CN)
SE81(VMM)MOUNT
MARKED:MOUNT TABLE(IMMUNITY H-PHONE)
3
21
3
21
SE-80/81 BOARD (SIDE B) SE-80/81 BOARD (SIDE A)
12345678
A
B
C
D
E
F
09
1-672-459-
11
1-672-465-
11 21
