6-5
Ref. No. Part No. Description Ref. No. Part No. Description
DSC-P31/P31M
< RESISTOR >
R102 1-218-943-11 RES-CHIP 150 5% 1/16W
R103 1-218-943-11 RES-CHIP 150 5% 1/16W
R104 1-218-943-11 RES-CHIP 150 5% 1/16W
R105 1-218-943-11 RES-CHIP 150 5% 1/16W
R106 1-218-943-11 RES-CHIP 150 5% 1/16W
R107 1-218-943-11 RES-CHIP 150 5% 1/16W
R108 1-218-990-11 SHORT 0
R109 1-218-943-11 RES-CHIP 150 5% 1/16W
R110 1-218-943-11 RES-CHIP 150 5% 1/16W
R111 1-218-943-11 RES-CHIP 150 5% 1/16W
R112 1-218-943-11 RES-CHIP 150 5% 1/16W
R113 1-218-943-11 RES-CHIP 150 5% 1/16W
R114 1-218-943-11 RES-CHIP 150 5% 1/16W
R115 1-218-990-11 SHORT 0
R116 1-218-977-11 RES-CHIP 100K 5% 1/16W
R118 1-208-635-11 RES-CHIP 10 5% 1/16W
R119 1-218-990-11 SHORT 0
R121 1-218-990-11 SHORT 0
R122 1-218-990-11 SHORT 0
R123 1-218-990-11 SHORT 0
A-7078-175-A FP-527 BOARD, COMPLETE
***********************
A-7078-116-A JK-223 BOARD, COMPLETE
***********************
< CONNECTOR >
CN202 1-794-962-11 CONNECTOR, SQUARE TYPE (USB 5P) (USB)
CN203 1-766-340-21 CONNECTOR, FFC/FPC 10P
< DIODE >
D201 8-719-075-15 DIODE MAZT082H08S0
D206 8-719-073-01 DIODE MA111- (K8).S0
D207 8-719-073-03 DIODE MA8082- (K8).S0
D208 8-719-073-03 DIODE MA8082- (K8).S0
< FERRITE BEAD >
FB202 1-500-284-21 FERRITE 0uH
< JACK >
J201 1-569-950-31 JACK (SMALL TYPE) (VIDEO OUT)
< LINE FILTER >
LF201 1-419-100-21 INDUCTOR 0uH
LF202 1-419-100-21 INDUCTOR 0uH
< RESISTOR >
R202 1-218-953-11 RES-CHIP 1K 5% 1/16W
R204 1-216-864-11 METAL CHIP 0 5% 1/16W
R205 1-500-284-21 FERRITE 0uH
R206 1-216-864-11 METAL CHIP 0 5% 1/16W
CH-109 JK-223 PK-062
< VARISTOR >
VDR201 1-803-974-21 VARISTOR, CHIP
A-7078-119-A PK-062 BOARD, COMPLETE
***********************
< BATTERY >
BT401 1-756-191-11 BATTERY, LITHIUM (SECONDARY)
< CAPACITOR >
C401 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C402 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C403 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C404 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C407 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C408 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C409 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C410 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C412 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C420 1-117-746-81 CERAMIC CHIP 8PF 16V
C421 1-117-746-81 CERAMIC CHIP 8PF 16V
C422 1-164-931-11 CERAMIC CHIP 100PF 10% 50V
C423 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C801 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C804 1-165-877-91 TANTAL. CHIP 33uF 20% 6.3V
C805 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C807 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C808 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C809 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C810 1-164-931-11 CERAMIC CHIP 100PF 10% 50V
C812 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C813 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C814 1-135-177-21 TANTALUM CHIP 1uF 20% 20V
C815 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C816 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C817 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C818 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C819 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
C820 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C821 1-164-357-11 CERAMIC CHIP 0.001uF 5% 50V
C822 1-113-994-11 TANTAL. CHIP 6.8uF 20% 16V
C823 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C824 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C825 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C826 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C829 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C830 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C832 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C833 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C834 1-137-910-11 TANTAL CHIP 10uF 20% 16V
(suffix-12) (Note)
C835 1-137-910-11 TANTAL CHIP 10uF 20% 16V
(suffix-12) (Note)
C901 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
(Note) Information about printed wiring boards with
suffix-12 is printed in the supplement-1.
To Next Page
