2-14. FLEXIBLE BOARDS LOCATION
2-13. CIRCUIT BOARDS LOCATION
PK-062
CD-391
CH-109
JK-223
SY-075
ST-068
Board Name Function
CD-391 CCD IMAGER
CH-109 CAMERA PROCESS
JK-223 JACK
PK-062 FRONT CONTROL, LCD DRIVE, TIMING GENERATOR,
CONTROL SWITCH
ST-068 FLASH DRIVE
SY-075 CAMERA DSP, VIDEO, MEMORY, LENS DRIVE, SH DSP,
FLASH MEMORY CLOCK GENERATOR, CONNECTOR, DC IN,
DC/DC CONVERTER
FP-529
FP-067
FP-069
FP-530
FP-527
FP-076
FP-071
FP-073
