6-4
6-2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Ref. No. Part No. Description
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
DSC-P31/P31M
CD-391 CH-109
•Abbreviation
AUS: Australian model
CH : Chinese model
CND : Canadian model
HK : Hong Kong model
A-7078-120-A CD-391 BOARD, COMPLETE
***********************
(IC301 is not included in this complete board)
< CAPACITOR >
C301 1-125-827-91 CERAMIC CHIP 1uF 10% 25V
C302 1-113-992-11 TANTAL. CHIP 3.3uF 20% 35V
C303 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C304 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C305 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
C306 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C307 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C308 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C309 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C310 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C311 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
< CONNECTOR >
CN301 1-766-350-21 CONNECTOR, FFC/FPC 20P
< DIODE >
D301 8-719-073-01 DIODE MA111- (K8).S0
< FERRITE BEAD >
FB301 1-414-228-11 FERRITE 0uH
< IC >
IC301 A-7031-357-A CCD BLOCK ASSY (Note)
< COIL >
L301 1-469-561-21 INDUCTOR 100uH
< TRANSISTOR >
Q301 8-729-052-64 TRANSISTOR DTC144EHT2L
Q302 8-729-050-22 TRANSISTOR 2SC4250 (T5LSONY1)
< RESISTOR >
R301 1-218-977-11 RES-CHIP 100K 5% 1/16W
R302 1-218-941-11 METAL CHIP 100 0.5% 1/16W
R303 1-220-802-11 RES-CHIP 3.3 5% 1/16W
R304 1-220-802-11 RES-CHIP 3.3 5% 1/16W
R305 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R306 1-218-990-11 SHORT 0
R307 1-218-981-11 RES-CHIP 220K 5% 1/16W
R308 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
< THERMISTOR >
TH301 1-810-816-11 THERMISTOR, NTC (1608)
A-7078-118-A CH-109 BOARD, COMPLETE
(Including IC101 (CH-111 Board))
***********************
< CAPACITOR >
C103 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C105 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C106 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C107 1-164-506-11 CERAMIC CHIP 4.7uF 16V
C108 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C109 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
< CONNECTOR >
CN101 1-793-128-21 CONNECTOR, BOARD TO BOARD 70P
CN102 1-779-334-11 CONNECTOR, FFC/FPC 20P
< FERRITE BEAD >
FB101 1-469-082-21 FERRITE 600uH
FB102 1-414-228-11 FERRITE 0uH
FB103 1-469-082-21 FERRITE 600uH
FB105 1-414-228-11 FERRITE 0uH
FB106 1-414-228-11 FERRITE 0uH
< COIL >
L101 1-469-559-21 INDUCTOR 47uH
L102 1-469-555-21 INDUCTOR 10uH
L103 1-469-555-21 INDUCTOR 10uH
(Note) Be sure to read “Note on the CCD Imager
Replacement” on page 4-8 when changing
the CCD imager.
KR : Korean model
JE : Tourist model
J: Japanese model
• DSC-P31M is the same as DSC-P31 (US model)
except packing materials. Therefore, information
about DSC-P31 (US model) in the text is applied.
To Next Page
