DSR-45/45P
Address
Initial value
Remark
NTSC PAL
44 to 46 Fixed data-1 (Initialized data)
47 20 20 PLL f
0
adj.
48 to 63 Fixed data-1 (Initialized data)
64 Fixed data-2
65 to 72 Fixed data-1 (Initialized data)
73 03 03 CLK DELAY and AEQ adj.
74 to 8F Fixed data-1 (Initialized data)
90 Fixed data-2
91 to A2 Fixed data-1 (Initialized data)
A3 Fixed data-2
A4 to A9 Fixed data-1 (Initialized data)
AA Fixed data-2
AB to BD Fixed data-1 (Initialized data)
BE Fixed data-2
BF to C1 Fixed data-1 (Initialized data)
C2 Fixed data-2
C3 to DF Fixed data-1 (Initialized data)
Address
Initial value
Remark
NTSC PAL
00 to 0F Fixed data-1 (Initialized data)
10 EE EE
11 00 00
Switching position adj.
12 EE EE
13 00 00
14, 15 Fixed data-1 (Initialized data)
16 E0 E0 Capstan FG adj.
17 Fixed data-1 (Initialized data)
18 2A 2A
CLK DELAY and AEQ adj.
19 2A 2A
1A Fixed data-1 (Initialized data)
1B 33 33
CLK DELAY and AEQ adj.
1C 33 33
1D Fixed data-1 (Initialized data)
1E 25 25 RF-AGC adj.
1F 3E 3E
PLL f
0
adj.
20 3E 3E
21 DC DC CLK DELAY and AEQ adj.
22 99 99 PLL f
0
adj.
23, 24 Fixed data-1 (Initialized data)
25 88 88
Playback Y level adj./
Monitor terminal output Y level adj.
26 E3 E3
Playback C level adj./
Monitor terminal output C level adj.
27 A1 A1
Playback C level adj./
Monitor terminal output C level adj.
28 to 2B Fixed data-1 (Initialized data)
2C 08 08
2D 00 00
2E 46 46
2F 01 01
Node unique ID No. input
30 02 02
31 00 00
32 00 00
33 00 00
34
35
Fixed data-2
36
37
38 00 00
39 00 00
3A 00 00
3B 00 00
3C 00 00
3D 00 00
Emergency memory
3E 00 00
3F 00 00
40 00 00
41 00 00
42 00 00
43 00 00
6. C Page Table
Note: Fixed data-1: Initialized data. (Refer to “Input of C page
Initial Data”)
Fixed data-2: Modified data. (Refer to “Modified of C, D,
E Page Data”)
