1. NOTE FOR REPAIR
Make sure that the flat cable and flexible board are not cracked of
bent at the terminal.
Do not insert the cable insufficiently nor crookedly.
When remove a connector, don’t pull at wire of connector.
It is possible that a wire is snapped.
Cut and remove the part of gilt
which comes off at the point.
(Be careful or some pieces of
gilt may be left inside)
When installing a connector, don’t press down at wire of connector.
It is possible that a wire is snapped.
SERVICE NOTE
Do not fold down a flat cable at the edge of the inforcing board
which is the reverse side of pins when the flat cable is connected
to a connector.
If the flat cable is folded at that point, it may be a cause of
breaking of foil inside of the cable.
