Menu Configuration and Basic Menu Operations
Function menu (with the DXC-637 series)
Menu Control item Function
Operation Jump menu 1 To jump to the adjustment screen designated for Menu 1 in Menu Set (Default: White of Paint 1)
Jump menu 2 To jump to the adjustment screen designated for Menu 2 in Menu Set (Default:Black of Paint 1)
Jump menu 3 To jump to the adjustment screen designated for Menu 3 in Menu Set (Default: Flare of Paint 1)
Jump menu 4 To jump to the adjustment screen designated for Menu 4 in Menu Set (Default: Gamma/Knee of
Paint 1)
Jump menu 5 To jump to the adjustment screen designated for Menu 5 in Menu Set (Default: Detail of Paint 2)
Jump menu 6 To jump to the adjustment screen designated for Menu 6 in Menu Set (Default: Skin Detail of
Paint 2)
Jump menu 7 To jump to the adjustment screen designated for Menu 7 in Menu Set (Default: Matrix of Paint
3)
Shutter To turn the shutter function ON/OFF
• Shutter To select the shutter speed
CLS To turn the CLS (clear scan) function ON/OFF
• CLS To select the CLS frequency
• Master Gain To select the master gain setting from among Hi/Mid/Low
SW ATW To turn the ATW (auto tracing white balance) function (which automatically adjusts the white
balance when lighting conditions change) ON/OFF
Auto Knee To turn the Auto Knee function ON/OFF
Lens/Pan Option 1 To turn the option control function 1 ON/OFF
Option 2 To turn the option control function 2 ON/OFF
• Focus
a)
To adjust the focus
• Zoom
a)
To adjust the zoom
• Pan
b)
To adjust panning of the tripod head
• Tilt
b)
To adjust tilting of the tripod head
The submenu “Menu Set” can be selected from Security of RCP Config on the OTHERS menu.
The item “Lens/Pan” is displayed when Pan/Tilt Enable is set to ON with Security of RCP Config on the OTHERS menu.
a) To control the lens from this unit, the optional focus zoom servo unit and the interface unit for the camera adapter and lens are required.
b) To control the tripod head from this unit, an electric tripod head and the interface unit for the camera adapter and tripod head are required.
